Our newly purpose built 3300sqm production facility located only 20km to Qingdao port that is the largest port in China for glass export. We take the advantage of this location to reduce the cost in logistics and lessen the lead time that all ultimately contributed to the success of our customers (may need a map here). We have some of the latest glass processing equipment in house to meet any specifications our customer required, including:
- Convection Toughening Furnace (Low E, Bent Glass)
- Horizontal Glass Tempering Furnace
- DGU/IGU Line
- Vertical CNC
- Automatic Drilling Center
- Automatic Edging Center
- Two Straight Line Edgers
- Double Edger
- Irregular Edger
- Automated Glass Washing Machine
- Containerisation Platform
- Automated DGU Spacer Creation Machine
Our Manufacturing Capacity
| Flat Toughened | Bent Toughened (2) | Low E Flat Toughened | Low E Bent Toughened (2) | Double Glazed (1) | Mirror | |
|---|---|---|---|---|---|---|
| Min. Size (mm) | 220 x 150 | 350 x 350 | 220 x 150 | 350 x 350 | 220 x 150 | ∞ |
| Max. Size (mm) | 4000 x 1700 | 1200 x 1700 | 4000 x 1700 | 1200 x 1700 | 4000 x 1700 | ∞ |
| Min. Thickness (mm) | 2.85 | 3.1 | 2.85 | 3.1 | 4 + 6A + 4 | ∞ |
| Max. Thickness (mm) | 19 | 15 | 19 | 15 | 6 + 27A + 6 | ∞ |
| Min. Radius(mm) | -- | 550 | -- | 550 | 550 (4) | -- |
| Coated | √ | √ | √ | √ | √ | √ |
| Beveled | √ | √ | √ | √ | √ | √ |
| Irregular Edge | √ | √ | √ | √ | √ | √ |
| Holes | √ | √ | √ | √ | √ | √ |
| Cut Out | √ | √ | √ | √ | √ | √ |
| Laminated | √ | √ | √ | √ | √ | -- |
| Sandblasting (3) | √ | √ | √ | √ | √ | √ |
| Silk Print | √ | √ | √ | √ | √ | √ |
| Colored | √ | √ | √ | √ | √ | √ |
| Safety Film | √ | √ | √ | √ | √ | √ |
- DGU is to be manufactured in line with customers’ requirements in gas fill (eg. Argon), spacer material, spacer color, inner-frame etc.
- The viability of bent glass will depend on the combination of glass thickness, radius, length and depth and curve.
- The density of sandblasting (matte effect) can be adjusted based on customers’ requirement.
- Bent glass can also be double glazed in line with customer’s requirement.
- We also supply all different types of float glass with a very competitive price.
- Any sizes or other special requirements that not demonstrated in this chart, please contact us on enquiry@trilliance.com.au to find the right solutions.
